PoE Splitter, Gigabit, Adjustable 5V/9V/12V/18V Output (30W Max)

N89.PSG2

This versatile Gigabit PoE Splitter is designed to power non-PoE devices by converting standard PoE input (36–57V DC) into selectable DC outputs of 5V, 9V, 12V, or 18V. Fully compliant with IEEE 802.3af/at, it supports Gigabit Ethernet (10/100/1000 Mbps), making it ideal for a wide range of IP-based deployments.

The splitter supports up to 30W output power, and includes intelligent features such as thermal cutoff, short-circuit protection, and high-efficiency DC/DC conversion—all in a compact wall-mount form factor. Built for reliability and flexibility, this device enables streamlined installations by combining data and power through a single Ethernet cable.

How To Buy

Download Spec Sheet

  • Fully compliant with IEEE 802.3af/at PoE standards
  • Adjustable output voltage: 5V, 9V, 12V, or 18V
  • Supports Gigabit Ethernet (10/100/1000 Mbps)
  • Built-in thermal cutoff and short-circuit protection
  • Auto-sensing PoE input with wide voltage range (36–57V DC)
  • Integrated high-efficiency DC/DC converter
  • Plug-and-play setup with LED indicators for PoE readiness
  • Compact design with wall-mount capability

Material Specifications

Data Rates 10/100/1000 Mbps
Ethernet Ports 1 x RJ45 PoE IN (Data + Power); 1 x RJ45 LAN OUT (Data only)
DC Output Interface 1 x 5.5mm x 2.1mm Barrel Jack
Input Power Voltage 36–57V DC
Power Output Adjustable: 5V/3A | 9V/2.5A | 12V/2.5A | 18V/1.6A
Maximum Output Power Up to 30W
Power Standard Compliance IEEE 802.3af / IEEE 802.3at
LED Indicators PoE Status / In-Use
Connectors Shielded RJ45, EIA/TIA 568A & 568B compliant
EMI / EMC Compliance EN 55022 Class B (Emission), EN 55024 (Immunity), VCCI
Regulatory Compliance IEEE 802.3af/at (PoE) | IEEE 802.3 (Ethernet) | IEEE 802.3u (Fast Ethernet) | IEEE 802.3ab (Gigabit Ethernet) | RoHS Compliant | CE | FCC
Reliability MTBF : 100,000 hours @ 25°C
Dimensions 78mm × 73mm × 28mm

Environmental Specifications

Temperature range Storage & shipping -20°C to +70°C
Operation 0 to 40°C
Humidity Tolerance Storage Max 95% RH (non-condensing)
Operation Max 90% RH (non-condensing)
