NebulaView 18.5” LCD KVM Over IP Switch, 8-Port, Dual Access (1 Local + 1 Remote)

N932.KOIP188

The NebulaView 18.5” LCD KVM Over IP Switch combines a high-resolution LCD display, full keyboard, and integrated trackball into a compact 1U rackmount design. It offers secure, centralized control over up to 8 servers or PCs, with dual access support for 1 local user and 1 remote user simultaneously. Through TCP/IP connectivity, administrators can manage their systems from anywhere via LAN, WAN, or the Internet — with no additional software or drivers required. With compatibility across all major operating systems, this KVM is an ideal solution for enterprise server rooms, data centers, and IT environments requiring high-performance, remote BIOS-level access.

How To Buy

Download Spec Sheet

  • 18.5” Full HD TFT LCD with 1920×1080 @ 60Hz resolution
  • Slim 1U rack-mountable design, fits standard EIA 19” racks
  • Full-size 99-key keyboard with numeric pad
  • Integrated trackball mouse eliminates external accessories
  • Dual power supply for redundancy and reliability
  • RJ-45 interface with Cat5e/6 cabling up to 100m distance

Material Specifications

Computer Connections (Direct / Max) 8 / 8
Port Selection Button, Hotkey, Web UI
Display Type 18.47″ Full HD TFT LCD
Display Resolution 1920 × 1080 @ 60Hz
Color Depth 16.7 Million
Brightness 250 cd/m²
Contrast Ratio 1000:1
Pixel Pitch 0.213 (H) × 0.213 (W) mm
Mouse X/Y resolution > 1000 points/inch; Scroll Wheel supported
Keyboard 99 keys (82 standard + 17 number pad)
Remote Access Protocols Web Browser, ActiveX Client
Remote Video Resolution Up to 1920×1080 @ 60Hz
Security DES / AES / 3DES encryption
Power Input 100 – 240V AC, 50–60Hz, <1.5A
Power Consumption 23W
Mounting Distance 686 – 770 mm (L=262 mm), customizable
Net Weight 11.9 kg
Product Dimensions (W × D × H) 448mm × 560mm × 42.5mm

Environmental Specifications

Operating Temperature Range 0°C to 50°C
Storage Temperature Range -20°C to 60°C
Humidity 0–80% RH (non-condensing)
